VSS W08POE2G 8*100 + 2*1000 PoE Switch

VSS W08POE2G PoE Switch

Description

VSS W8POE2G is a 10-port Gigabit PoE switch featuring 16 × 10/100M PoE+ ports, 2 × 10/100/1000M RJ45 uplink ports. Ports 1–16 support IEEE 802.3af/at standards, offering up to 30 W per port with a total PoE budget of 300 W. Numerous AI features include:
– AI Extend: data transmission up to 300 m distance (10 Mbps),
– AI VLAN: port-to-port isolation on ports 1–16,
– AI PoE Watchdog: automatic restart and recovery,
– AI Testing: PoE/Network diagnostics mode.

Fanless metal enclosure, IP30 protection class, built-in 300 W power supply and IEC-certified surge/ESD protection make the device suitable for 24/7 video surveillance, base stations, VoIP and access control applications.

Ports

• Fixed ports:
  16 × 10/100M PoE (data/power)
  2 × 10/100/1000M RJ45 uplink

• PoE standard: IEEE 802.3af/at

• Maximum power per port: 30 W / 15.4 W average

• PoE total budget: 300 W

• PoE terminals: 1/2 (+), 3/6 (–)

AI Features

• E – Extend: up to 300 m, limited to 10 Mbps

• V – VLAN: isolation of ports 1–16

• D – AI PoE Watchdog: automatic PoE recovery

• T – AI Testing:
  • UP: automatic PoE status detection
  • DOWN: automatic network status detection

Protocols

• IEEE802.3 10BASE-T

• IEEE802.3i 10Base-T

• IEEE802.3u 100Base-TX

• IEEE802.3ab 1000Base-T

• IEEE802.3z 1000Base-X

• IEEE802.3x

Performance

• Autonegotiation: 10/100/1000Base-T(X), full/half duplex, MDI/MDI-X

• Forwarding mode: Store-and-Forward

• Switching capacity: 20 Gbps

• Throughput: 14.88 Mpps

• MAC table: 8K

• Buffer memory: 2 MB

• Copper cable transmission distance:
  • 10BASE-T: Cat5 up to 250 m
  • 100BASE-TX: Cat5 or better up to 100 m
  • 1000BASE-T: Cat5 or better up to 100 m

Power

• Built-in power supply: AC 100–240 V, 50–60 Hz, 300 W

• Power consumption:
  • Standby: <4 W
  • Full load: <120 W

LED Indicators

• Indicators:
  • PWR (green)
  • Ports 1–8: Link/Act (green)
  • Ports 9–10: Link/Act (green)

Environment

• Operating temperature: –20°C to +55°C; 5–90% RH

• Storage temperature: –40°C to +75°C; 5–95% RH

Protection

• ESD: IEC61000-4-2: ±8 kV contact, ±15 kV air

• Surge impulse: IEC61000-4-5:
  • Power CM ±4 kV / DM ±2 kV
  • Port ±4 kV

• Protection class: IP30

Dimensions

• Size: 200 × 105 × 29 mm

• Weight: <1.8 kg (net) / <2.5 kg (gross)

Installation

• Methods: desktop mounting, wall mounting, 19-inch 1U rack mounting

Certifications

• Compliance: CCC, CE, CE/LVD EN60950, FCC Part 15 Class B, RoHS

Package Contents

• VSS W8POE2G switch × 1

• Mounting brackets (hanging ears) × 1 pair

• User manual × 1
