Apollo XP95 addressable optical smoke detector 55000-620APO

The XP95 optical smoke detector uses the light-scattering principle to detect a wide range of slow-burning and smouldering fires quickly and effectively.

  • Reliable fire detection in areas with temperatures from –20 °C to +60 °C
  • Ideal for escape routes
  • Unaffected by wind or air pressure

Manufacturer's recommended service life: 10 years Applications

  • Escape routes
  • Hotels
  • Offices
  • Restaurants
  • Retail premises
  • Bedrooms
  • Medium and large buildings

Fire type

  • Slow-burning and smouldering fires

Colour - White Sensor configuration - Horizontal optical chamber with infrared emitter and sensor, arranged radially to detect forward-scattered light Weight - 105 g Housing material - Polycarbonate Terminal material - Nickel-plated stainless steel Product height - 42 mm Product diameter - 100 mm Detection principle - Photoelectric light scattering Nominal analogue value - 25 Analogue value tolerance - +7 / –7 Alarm level analogue value - 55 Chamber type - Chevron Voltage - 5 to 9 V Power-up surge current - 1 mA Maximum power-up time - 4 seconds Status indicator – alarm - Red Status indicator – fault Off Quiescent current - 340 μA Supply voltage - 17 to 28 V DC Terminal functions

  • L2: +L2 loop in and out, positive, double terminal
  • L1 in: –L1 loop in and out, double terminal
  • +R: remote indicator positive connection
  • –R: remote indicator negative connection

Polarity - L1 and L2 are polarity-insensitive Battery powered - No Sampling frequency - Once per second Humidity - 0% to 95% RH (non-condensing, non-icing) Operating temperature - –20 °C to +60 °C Storage temperature - –30 °C to +80 °C Effect of wind speed - None Datasheet CPR certificate DoP certificate DoC certificate

Product codeK002222
Manufacturer code55000-620APO
BrandApollo
ConditionNew
Warranty24 months
