Ajax GlandBox mounting base black

Ajax GlandBox mounting base

Ajax GlandBox is a dedicated mounting accessory designed for use with the EN54 Fire Hub Jeweller control panel. It provides neat, standards-compliant cable entry to the control panel, especially where concealed in-wall cabling is not possible, for example in historic buildings or temporary installations.

Key features and specifications:

• Clean, professional cable entries:
  The GlandBox has 16 cable entries across four sides

• Easier installation:
  A built-in spirit level, “UP” marking and CIE centre line marking help you install it quickly and accurately

• Tamper protection:
  The GlandBox has knock-outs that allow the EN54 Fire Hub Jeweller tamper switch to be used — the system notifies you if the device is removed or the GlandBox is opened

• Material and design:
  Made of plastic, available in black or white. The material has a UL 94 V-0 flammability rating and an IP20 protection rating

• Dimensions and weight:
  The GlandBox measures 263 × 223 × 40 mm and weighs 335 g

• In the box:
  Includes the GlandBox enclosure, mounting kit and quick start guide. Cable glands are not included

Summary table

What is it used for?

• Ensures neat and secure cable management, especially where concealed in-wall cabling cannot be used.

• The design is perfectly matched to the look of the Fire Hub, helping to keep the system looking tidy and professional.

• Tamper protection and precise installation aids provide extra peace of mind and compliance with the standards that are critical in EN54 fire alarm systems.
