Ajax EN54 FireProtect (VAD) wireless visual alarm device, red

Ajax EN54 FireProtect (VAD) Jeweller

FireProtect (VAD) Jeweller is a wireless visual alarm device (VAD) that complies with the European fire safety standards EN 54-23 and EN 54-25, as well as the Radio Equipment Directive RED (2014/53/EU). The device runs on Ajax's robust Jeweller radio protocol, providing a reliable and secure connection to the EN54 Fire Hub control panel, directly or via Fire ReX.

Visual alarm (VAD)

• The device produces a visual alarm using an LED frame that flashes in a 90 ms on / 1,910 ms off pattern, with a cycle period of 2,000 ms (0.5 Hz).

• Particularly suitable for noisy environments or areas with limited audibility, such as wide corridors, large halls and ice rinks, or for ensuring the safety of people with hearing impairments.

Sound signal

• The VAD relies on visual signalling and has no audible alarm (unlike the Sounder/VAD model).

Communication and security

• Uses the Jeweller radio protocol, which supports two-way communication and automatic frequency hopping to avoid interference.

• Communication range of up to 1,700 m in open space; also compatible with the Fire ReX range extender.

• Automatic tamper protection and AES encryption keep the system secure.

Power supply and battery life

• Powered by 4 × CR123A batteries, pre-installed, with a battery life of up to 5 years.

Physical characteristics and installation suitability

• Dimensions: 145 × 145 × 51 mm

• Weight: 561 g

• IP rating: IP54 — suitable for both indoor and sheltered outdoor conditions

• Temperature: –10 °C … +50 °C

• Humidity: up to 80%

• Available colours: white, black and red (the red model is especially eye-catching).

Summary table
