Akuvox R20K-L apartment building intercom door station 4G with power

Stylish Akuvox R20K-L video intercom door station for apartment buildings with 4G (LTE) support.

Sometimes running or replacing cables simply isn't practical. It can be expensive, time-consuming or difficult, especially in older apartment buildings, homes or commercial premises.
Using modern mobile network technology, the Akuvox R20K-L video intercom door station offers a smart, cost-effective solution that works entirely without data cables. Only a power cable is needed to power the device.
With its elegant design and robust construction, the R20K-L suits any setting, combining convenience, security and a modern look in one compact device.

Key features

• Stylish aluminium panel with a durable numeric keypad

• Linux operating system: stable and secure operation

• Wide-angle camera: 110° (horizontal) / 58° (vertical)

• Two-way audio over IP networks with echo cancellation: crystal-clear sound at both ends

• LTE technology: minimal installation, no data cables or complex network connection required

• Mounting options: both flush and surface mounting

Why choose the Akuvox R20K-L?

• Ideal for older buildings or locations where running cables is difficult
• Easy installation and low maintenance costs
• Modern design that suits any setting
• A secure, reliable and future-proof choice

Door station specifications

• Front panel material: aluminium alloy, black
• Camera: 2MP, video resolution up to 1920x1080p
• Camera field of view: 110°(H) / 58°(V)
• IR illumination on camera
• Motion detection
• Keypad
• RS485
• Card reader: 13.56MHz, NFC (Android phones only)
• Relay outputs: 2
• Inputs: 2
• LAN interface: RJ45, 10/100Mbps adaptive
• SIM card slot
• 4G (LTE) module included
• 802.3af Power-over-Ethernet
• IP rating: IP65
• Mounting: surface. Flush mounting requires a separate back box (available to order).
• Dimensions: 185 x 84.5 x 24mm
• Operating temperature: -30°C ~ +60°C
• Akuvox Cloud: supported
• Can be connected to video surveillance recorders (please check compatibility with us)

Please note: The 4G module in this door station is used only to provide a mobile internet connection. Direct calls are not possible. Calls only work via VoIP or using the corresponding app.
If you have any questions about using the system, please contact our specialists. Datasheet: Akuvox R20K-L Black Datasheet Manufacturer's page: R20K-L - Akuvox Video: R20K-Akuvox
