AA-07FBI Silver Apartment Intercom Door Station, BAS-IP

AA-07FBI- Silver audio door entry panel, basIP

AA-07FBI is an audio door entry panel designed for apartment buildings, which supports facial recognition and the BAS-IP UKEY mobile application.

The device is equipped with a backlit TFT color screen and a high-resolution IP camera with a wide viewing angle that ensures a clear image even in various lighting conditions.

The panel also has a TRS jack for connecting an external induction loop, which is intended for users with hearing impairments. The induction loop operates with low-frequency audio signals (1.2 V / 8.2 kΩ).

Additionally, the device supports PoE power (Power over Ethernet), which makes installation easier and more convenient.

Technical specifications:

Panel type: Apartment building audio door entry panel
Induction loop: Yes, separate module
Screen: 4.3″ TFT color screen with backlight
Resolution: 2.0 MP
Camera viewing angle: 110° (horizontal)
Video output: 1080p (1920×1080), H.264 Main Profile
Night lighting: 6 LEDs
Light sensitivity: 0.01 Lux
Impact resistance: IK07
Protection class: IP65
Operating temperature: −40…+65 °C
Operating humidity: 0–86%
Power consumption: 6.5 W, standby mode 3.6 W
Power supply: +12 V DC (+8% / −4%)
Housing: Aluminium
Color: Silver
Dimensions: 155 × 375 × 55 mm
Installation: Flush-mounted installation, wall-mounted installation with BR-AA bracket
Keyboard: Backlit mechanical buttons
Package dimensions: 431 × 200.5 × 97 mm
Gross weight: 2.68 kg
User interface: Multilingual, WEB interface

Door opening

• via monitor
• with facial recognition
• via QR code
• via guest link
• with PIN code
• with access card
• with license plate recognition
• with BAS-IP Link application
• with BAS-IP Intercom application
• with BAS-IP UKEY application
• via API

Access control

• facial recognition
• UKEY (EM-Marin / MIFARE® / NFC / Bluetooth)
• multi-factor authentication

Supported standards

BLE (Bluetooth Low Energy):
2.45 GHz Bluetooth 4.x, Bluetooth 5.x

MIFARE®, 13.56 MHz ISO14443A:
Mifare® Standard, Hi-Memory, Ultralight, Classic 1K/4K, Classic 7UID, Plus SL1 and SL3, Light ID, Desfire EV1, Desfire EV2

NFC, 13.56 MHz:
ISO 14443 / 15693

Cards 125 kHz:
ASK and FSK

Reading distance

• NFC, MIFARE and 125 kHz cards – up to 5 cm
• BLE – adjustable 10 cm to 10 m

Additional functions

Elevator call to floor: Yes (requires elevator controller)
Facial recognition users: up to 10,000 faces
Identifiers stored in panel memory
(QR codes, cards, key fobs, UKEY, access codes): up to 20,000
ONVIF (Profile S): Yes
Integration with access control systems: Wiegand
Built-in Wiegand output
(for cards, key fobs and UKEY):
26, 32, 34, 37, 40, 42, 56, 58, 64, 80 bits

Induction loop connection for people with hearing impairments

Output: low-frequency audio signal 1.2 V; 8.2 kΩ
Connection type: TRS jack (female)

SH-12 additional module support

• Wiegand input: 6–58 bits
• Wiegand output (card, key fob, UKEY, QR, Face, PIN etc.): 26–128 bits

Quick call buttons

• concierge call button

Ringtones: 4 polyphonic ringtones

Authentication

• separate password for settings
• WEB interface

Additionally

• Link software support
• SIP P2P
• built-in relay
• Open API

Product sheet: AA-07FBI

Manufacturer page: – AA-07FBI BAS-IP
