BI-02FBI Two-Button Intercom Entry Panel, Black, BAS-IP

BI-02FBI phone entry panel with two buttons, black

A unique outdoor panel designed for multi-apartment buildings with a stylish design and available in silver, black and gold color tones.
The device is equipped with three LED indicators that show the panel status, and it has an output for connecting an induction loop for users with hearing impairment.

Versions with 2, 4, 8 and 12 buttons are available (BI-02/04/08/12FBI).

For information and ordering of panels in different colors and button configurations, please contact us at [email protected].

The entry panel supports BAS-IP UKEY mobile access and allows direct calls to both indoor panels and administrators.
The device fits well with both small office and residential interiors.

Technical specifications:

Panel type: detached house, apartment building
Housing: Aluminium
Protection class: IP65
Impact resistance: IK08
Operating temperature: −40 °C to +65 °C
Dimensions: 156 × 370 × 50 mm
Colors: silver, black, gold
Installation: recessed or wall mounted (with separate bracket BR-AA12)
Camera sensor: 1/3″
Resolution: 2 MP
Video: 1080p (1920 × 1080), H.264 Main Profile
Viewing angle: 90° horizontal
Light sensitivity: 0.01 lux
Night lighting: 6 LEDs
Hearing impaired module: separate output for module connection (TRS socket)
Power supply and power consumption: 12 V DC, Power consumption: 6.5 W (standby mode 3.6 W)
Authentication methods: Facial recognition (models BI-08/BI12FBI), UKEY mobile access (EM-Marin/ MIFARE®/NFC/Bluetooth), cards and key fobs,
QR code, Guest access link, PIN code BAS-IP mobile applications, via API, License plate recognition (ANPR system),
Integration and interfaces: Wiegand output: 26–128 bits
Open API, SIP P2P support, Link software support.
Supported standards: Mifare® 13.56 MHz (Standard, Ultralight, Classic, Plus, DesFire etc.),
NFC, 125 kHz cards (ASK, FSK),
Reading range: NFC / Mifare / 125 kHz cards: up to 5 cm,
Additional features: Customizable notification sounds, integration with third-party systems, BAS-IP Link software support, SIP P2P, open API for creating integrations, flexible access rule creation, identifier validity management, lock control configuration.

Product sheet: BI-02FBI

Manufacturer page: BI-02FBI | BAS-IP
