Indoor monitor S562‑V vertical grey

Category: Indoor Monitor for IP Door Phone
Brand: Akuvox
Model: S562-V
Colour: Grey
Display: 7" (vertical), 1024 × 600
Power Supply: PoE, 12 V
Protocol: SIP
Alarm Inputs: 8 channels
Relay Outputs: 1
Call Inputs: 1
Technology: Linux
Model Code: 01039P11

General Specifications
Microphone: -42 dB
Speaker: 4 Ω / 2 W
Ethernet Ports: 2 × RJ45, 10/100 Mbps adaptive
Power over Ethernet (PoE): IEEE 802.3af
Power Input: 12 V DC plug (when PoE is not used)
Installation: wall or desk mount
Dimensions: 216.4 × 118.8 × 21.7 mm
Operating Humidity: 10–90%
Operating Temperature: -10 °C to +45 °C
Storage Temperature: -20 °C to +70 °C
Display
Display Mode: Normally White, Transmissive
LCD Screen Size: 7 inches (diagonal)
Resolution: 1024 × 600
Contrast Ratio: 600:1
Brightness: 250 cd/m²
Viewing Angle: 50° left, 50° right, 40° up, 50° down
Touch Screen: Projected Capacitive
Audio
SIP Protocol: SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband Audio Codecs: G.711a, G.711μ, G.729
Wideband Audio Codec: G.722
DTMF: Out-of-band DTMF (RFC2833), SIP INFO
Audio Features: Echo Cancellation
Network and Protocols
Supported Protocols: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Management and Maintenance
Auto Provisioning: supported
Web-based Management Portal: supported
Packet Capture: web-based packet recording
Configuration Backup and Restore: supported
Firmware Update: supported
System Logs: include door access logs
Video
Streaming Format: H.264
Applications
Private Homes and Villas
Apartment Buildings
Home Automation Systems
Modern Interiors
