Apollo addressable handheld with isolator SA5900-908APO

Apollo addressable manual call point with isolator SA5900-908APO The addressable manual call point (MCP) allows a fire alarm to be raised manually.

• Certified to EN 54-11 and EN 54-17
• Resettable operating element
• LED indicator with 170° visibility
• Suitable for both flush and surface mounting
• "Plug and Play" terminal connections for faster wiring
• Continuity link for testing the wiring before system commissioning
• Compatible with XP95, Discovery and CoreProtocol systems
• Built-in isolator

Manufacturer's recommended service life: 10 years Colour - Red Weight - 180 g Housing material - Polycarbonate Dimensions: - Length: 90 mm - Width: 90 mm - Depth: 63 mm Key type - Apollo manual call point reset key Nominal analogue value - 16 Alarm level analogue value - 64 Fault level analogue value - 4 Type - A Operating element - Resettable element Operation - Single action Protocol voltage - 5 to 13 V peak-to-peak Minimum protocol voltage - 5 V Maximum protocol voltage - 13 V Supply voltage - 17 to 35 V DC Switch-on surge current - 1 mA Maximum power-up time - 1 second Quiescent current - 100 μA (tested at 24 V DC) Status indicators

• Alarm: red
• Fault: yellow
• Isolation: yellow
• Polling/communication: flashing green

Polarity - L1 and L2 are polarity sensitive Humidity

• 0% to 95% RH
• No condensation or icing

Operating temperature - -40 °C to +70 °C IP rating - IP44
