Shelly Pro 2 - DIN Rail Mount Dual-Channel Smart Switch

Device identification

• Device name: Shelly Pro 2 v.1

• Device model: SPSW-202XE16EU

• Device SSID: ShellyPro2-XXXXXX

Short description
Shelly Pro 2 is a DIN rail mountable 2-channel smart switch with potential-free contacts. Thanks to the flexibility of its Gen2 firmware and LAN connectivity, it gives professional installers more options for end-user solutions. The device can work standalone on a local Wi-Fi network or via the cloud with home automation services.

Shelly Pro 2 can be accessed, controlled and monitored remotely from anywhere with an internet connection, as long as the device is connected to a Wi-Fi router and the Internet.

Shelly Pro 2 has a built-in web interface that can be used to monitor and control the device and adjust its settings.

Main applications

• Residential

• MDU (multi-dwelling units – apartments, hotels, etc.)

• Small businesses (offices, shops, restaurants, petrol stations, etc.)

• Government/municipal

• University/college

Integrations

• Google

• Alexa

• Samsung SmartThings

Device electrical interfaces
Inputs

• 2 switch/button inputs on screw terminals: SW1 and SW2

• 2 power supply inputs on screw terminals: 1 N and 1 L

• 2 relay inputs: I1 and I2

Outputs

• 2 relay outputs: O1 and O2

Ethernet port

• 1 RJ45 connector
  ⚠WARNING! Connect or disconnect the LAN cable only when the device is powered off! The LAN cable connector must not have any metal parts that the user touches when connecting or disconnecting it.

Add-on interface

• Shelly proprietary serial interface
  ⚠WARNING! High voltage on the add-on interface when the device is powered on!

Connectivity

• Wi-Fi

• Ethernet

• Bluetooth

Safety features

• Overheating protection

Supported load types

• Resistive (incandescent bulbs, heaters)

• Capacitive (capacitor banks, electronic devices, motor start capacitors)

• Inductive with RC snubber (LED light sources, transformers, fans, refrigerators, air conditioners)

Inputs

• One dome button

  • Press and hold for 5 s to reboot

  • Press and hold for 10 s to reset to factory settings

Outputs

• LED indicators

  • Power (red): on when power is connected

  • Wi-Fi (variable):

    • Blue: in AP mode

    • Red: in STA mode and not connected to a Wi-Fi network

    • Yellow: in STA mode, connected to a Wi-Fi network but not connected to Shelly Cloud or cloud service disabled

    • Green: in STA mode, connected to a Wi-Fi network and Shelly Cloud

    • Flashing red/blue: OTA update in progress

  • LAN (green): LAN connected

  • Out 1 (red): relay 1 closed

  • Out 2 (red): relay 2 closed

Technical specifications
Physical

• Size (HxWxD): 94x19x69 ±0.5 mm

• Weight: 76 g

• Mounting: DIN rail

• Screw terminals max. torque: 0.4 Nm

• Wire cross-section: 0.5–2.5 mm² (green), 0.5–1.5 mm² (blue)

• Wire strip length: 6–7 mm (green), 5–6 mm (blue)

• Enclosure material: Plastic

• Colour: Grey

Environmental

• Temperature: -20 °C to 40 °C

• Humidity: 30% – 70% RH

• Max altitude: 2000 m

Electrical

• Supply voltage AC: 110–240 V

• Supply voltage DC: N/A

• Power consumption: <3 W

• Neutral not required: No

Output circuit ratings

• Max switching voltage AC: 240 V

• Max switching voltage DC: N/A

• Max switching current AC: 16 A per channel, 25 A total

• Max switching current DC: N/A

Sensors, meters

• Internal temperature sensor: Yes

Radio

• RF frequency: 2400–2495 MHz

• Max RF power: <20 dBm

• Wi-Fi protocol: 802.11 b/g/n

• Wi-Fi range: up to 30 m indoors, 50 m outdoors (depending on local conditions)

• Bluetooth protocol: 4.2

• Bluetooth range: up to 10 m indoors, 30 m outdoors (depending on local conditions)

MCU

• CPU: ESP32-D0WDQ6

• Flash: 8 MB

Firmware capabilities

• Schedules: 20

• Webhooks (URL actions): 20, with up to 5 URLs per hook

• Scripting: Yes

• MQTT: Yes

• CoAP: No

Legend

• I1, I2 – load circuit input terminals

• L1(A) – load circuit 1 live (110–240 V)

• O1, O2 – load circuit output terminals

• L2(B) – load circuit 2 live (110–240 V)

• SW1, SW2 – switch/button input terminals

• L3(C) – device power supply live (110–240 V)

• L – live

• N – neutral

• LAN – RJ45 LAN connector
