Apollo XP95 addressable sensors base with isolator.

Apollo XP95 addressable detector base with isolator.

The isolating base detects and isolates short-circuit faults on the system loop. The base is loop-powered, polarity-sensitive and accepts an XPERT card, which sets the address of the associated device.

In the event of a short circuit, the base's integrated yellow LED indicator lights up. The fire detector fitted to the base remains active during a short circuit. Power and signals to the affected section of the loop are restored automatically once the fault has been cleared.

Supply voltage: 17–28 V DC + 9 V DC protocol pulses
Isolation indicator: yellow LED, continuously lit when isolated

Current consumption:

• At 18 V DC: 23 µA
• At 28 V DC: 43 µA
• At 18 V DC with adjacent section isolated: 4 mA

Maximum line current:

• Continuous, without isolation: 1.0 A
• Switching to isolation mode: 3.0 A

Operating temperature: −20 °C to +60 °C
Storage temperature: −30 °C to +80 °C
Humidity: 0–95% RH, non-condensing, no icing

Use: indoor use only

Dimensions: diameter 100 mm × height 24 mm
Weight: 100 g

Materials:

• Housing: white polycarbonate
• Terminals: nickel-plated stainless steel
