Ajax BulletCam HLVF (8 Mp), black

Ajax BulletCam HLVF (8 MP), black

Ajax BulletCam HLVF (8 MP) is a professional outdoor IP camera that combines 8-megapixel image quality, a motorised 2.8–12 mm varifocal lens and autofocus. With its adjustable focal length, the camera's field of view can be tailored precisely to the installation site, from a wide overview to closer monitoring of more distant objects.

The camera's True WDR 120 dB technology delivers a clear, detailed image even in challenging lighting conditions, such as strong backlight or large differences in brightness within the field of view.

For night-time surveillance, BulletCam HLVF uses hybrid illumination that combines infrared and white LED light. IR range is up to 60 m and white light range is up to 40 m. Smart illumination control adjusts the IR intensity to help prevent overexposure of nearby objects.

Built-in AI video analytics detects people, vehicles and animals and supports motion detection and line crossing detection. The camera supports recording to a microSD card of up to 256 GB and to an Ajax NVR.

The camera connects to the network via Ethernet and can be powered via PoE or a separate 12 V DC supply. Robust IP67 and IK10 protection makes the camera suitable for demanding outdoor conditions. The operating temperature range is −40…+60 °C according to Ajax product data.

Technical specifications

Parameter	BulletCam HLVF (8 MP)
Camera type	Wired IP bullet camera
Image sensor	1/2.7" CMOS
Maximum resolution	8 MP (3840 × 21600)
Frame rate	up to 25 fps
Lens	Motorised varifocal
Focal length	2.8–12 mm
Aperture	F1.6
Horizontal field of view	31°–111°
Vertical field of view	17°–57°
Diagonal field of view	35°–135°
Day/night	Yes, automatic
Hybrid illumination	IR + white LED
IR range	up to 60 m
White light range	up to 40 m
WDR	True WDR, 120 dB
Minimum illumination	colour 0.005 lx; B/W 0 lx
Video codec	H.265 / H.264
Image rotation	0°, 90°, 180°, 270°
AI object detection	People, vehicles, pets
Video analytics	Motion detection, line crossing
Microphone	Built-in
Audio codecs	G.711 μ-law, G.711 A-law, G.726, G.722
Recording	microSD up to 256 GB, Ajax NVR
MicroSD class	Class V30 or faster
Network interface	1 × RJ-45 Ethernet
Network speed	10/100 Mbps
ONVIF	Profile S / T*
Video protocol	JetSparrow
Power supply	PoE or 12 V DC
PoE	IEEE 802.3af / 802.3at
Power consumption	up to approx. 7.5 W
Ingress protection	IP67
Vandal resistance	IK10
Operating temperature	−40…+60 °C
Dimensions	242 × 90 × 90 mm
Weight	940 g
Colour	White / black

* Exact ONVIF profile support may depend on the firmware and integration used; Ajax describes BulletCam HLVF as an ONVIF-compatible camera.

Key selling point: in Ajax nomenclature, the HLVF designation means the camera features both HL – Hybrid Light and VF – Varifocal, i.e. hybrid illumination plus a variable focal length lens.

Datasheet: BulletCam HLVF all models Manufacturer's website: BulletCam HLVF all models User manual (EN): BulletCam HLVF
