Ajax ReX 2 – Signal booster for security systems

Ajax ReX 2 gives your Ajax security system flexibility and a secure coverage area. This intelligent wireless signal splitter allows you to connect detectors, or sensors with cameras, even if they are located far away from the central monitoring station, or if the location of the object is complex – for example in a large building, warehouse, multi-building estate or corporate office/hall environment.

Why choose ReX 2?

Large coverage and operating range – ReX 2 can transmit a signal between the hub and the equipment up to about 1 700 m in open area.
Visual alarm control and image capture – Unlike the first version of ReX, ReX 2 also supports image capture (preferably in combination with (e.g.) MotionCam or MotionCam Outdoor detectors), which means that in the event of an alarm, not only the signal but also the photos are transmitted – an important additional security measure.
Fast and reliable alarms – Alarms are transmitted in just 0.3 seconds.
Backup and sabotage protection – ReX 2 runs on 110-240 V, but the built-in Li-ion battery allows the unit to operate autonomously for up to around 38 hours in the event of a power failure. In addition, the unit supports sabotage, jamming and physical intrusion detection, as well as information security encryption to protect against signal interference.
Easy installation and setup – Connecting the ReX 2 to your system is simple: scan the QR code of the device with the Ajax app, test the signal strength and mount the device on the wall/wall using the SmartBracket plate. No complex wiring or special installation is required.
Suitable for large and complex sites – By connecting a single hub and up to five ReXs, the total system coverage can reach several hectares/ square kilometres – ideal for multi-building estates, large private houses, warehouses or industrial buildings.

Feature	Description
Type of device	Wireless signal extender (radio channel range extender)
Sideulatus (hub → ReX 2)	up to 1 700 m in open area
Communication (ReX 2 → detectors/equipment)	similar, depending on detector model and propagation conditions
Power supply / backup power	110-240 V + built-in Li-Ion battery, backup power up to ~ 38 h
Speed of alarm response	0,3 seconds
Picture mount support	Yes – in combination with photo-ready detectors (e.g. MotionCam, MotionCam Outdoor)
Security standards/encryption	Compliant with EN 50131 Grade 2, AES encryption, jamming and sabotage protection, frequency hopping, etc.
Number of amplifiers	Up to 5 ReX 2 per hub – depending on the hub
Installation	Indoor environment; installation with SmartBracket – quick and easy, no need to disassemble the enclosure

Who and what Ajax ReX 2 is for

Ajax ReX 2 is ideal if:

You need a security system for a large house, a villa, a warehouse or a multi-building property.
Your equipment (detectors, alarms, camera detectors, etc.) is located far away from the hub, or the layout needs to be spread out – e.g. garage, second house, barn, basement, office, hall.
You also want the security system to support visual (photo) alarm detection – be it motion, window/door opening or other detectors.
You want the system to work reliably even in the event of a power failure, and you want the signal to be secure even in the event of sabotage or signal interference.
You want a system that is flexible, expandable and easy to manage – suitable for private houses, commercial premises, warehouses/warehouses and multi-use properties.
